Winstar Road Supply is a leader in traffic-safety technology, delivering municipal-grade camera systems designed to improve roadway visibility, strengthen community security, and support safer public spaces. Our mission is to provide reliable, all-weather monitoring backed by professional US-based support.

The Winstar Municipal Traffic Camera Monitoring System provides high-definition video surveillance to monitor vehicle, pedestrian, and community activity in real time. Built for municipalities and law enforcement, this system is well-suited for roads, intersections, public facilities, and areas of elevated risk such as high-crime zones or drug activity hot spots. Its advanced optics and low-light performance ensure clear, consistent video capture day or night, in any weather. Municipalities can configure the system for roadway monitoring, pedestrian safety, neighborhood watch programs, or general security applications. This system is fully upgradeable — allowing municipalities to begin with camera-based monitoring today and later expand with radar and license plate recognition (LPR) for complete traffic data collection and enforcement.

With IP65-rated weather protection, AC or solar power options, and secure web-based control, the system delivers dependable performance and flexible deployment across diverse environments.

For long-term reliability and high-volume operation, we recommend A/C Wired power with a direct ethernet connection, installed by a Winstar Professional Installation Partner or a qualified local contractor. Please review our Recommended Installation Guide and Specifications.

Each Winstar Municipal Traffic Camera Monitoring System is custom made to order, please allow 1-3 weeks lead time.

Technical Specifications

Recommended Installation Guide

Winstar™ Municipal Traffic Camera Monitoring System

1 Year Free WinstarCloud Platform Subscription

1 Year Free 4G/5G Cellular Data Plan / Starlink Data Plan

Apple iPad 11" A16 (2025) Wi-Fi 128GB Included

Camera / Imaging:

• 12.3MP Sony IMX477 High-Resolution Sensor
• Full HD 1920×1080 Pixel Capture
• Low-Light Optimized; Optional IR Night Vision
• C-CS Mount, Motorized Telephoto Lens, PTZ (Pan-Tilt-Zoom) Module
• 4X Motorized Zoom; Day/Night Operation
• Optional Extended Zoom or Thermal Imaging Lens
• Supports Up To 4 Traffic Lanes (Standard: 2 Lanes)

Infrared Illuminator:

• 850 nm Infrared Light (Invisible to Naked Eye)
• 12 High-Power LEDs
• 90° Wide Beam Coverage
• Illumination Range Up to 65 Ft (20 M)
• Automatic Dusk-to-Dawn Operation
• IP67 Aluminum Housing With Reinforced Glass

Power Options:

• A/C Wired

• Battery / Solar (100W or 200W Panel, 12V 100Ah LiFePO₄ Battery with Built-In 100A BMS, 15,000+ Deep Cycles)

Communications:

• Wi-Fi 802.11 b/g/n
• GSM/Cellular 3G/4G/5G (2G Compatible)
• Standard SIM Slot
• 100 BASE-TX Wired Ethernet
• Optional Starlink Satellite Internet
• 1 Year Free 4G/5G Cellular Data Plan / Starlink Data Plan

Mechanical / Environmental:

• Camera Housing: IP65 Aluminum (White/Gray or Black)
• Camera Weight: 4lbs
• Control Enclosure: IP65 Galvanized Steel, 16"×12"×10", Thermostat & Fan-Controlled, White or Black Finish
• Operating Temperature: -40°F to 185°F

WinstarCloud:

• 1 Year Free WinstarCloud Platform Subscription

• View, Export, and Monitor All Collected Data in Real-Time From Any Internet-Connected Device.

Warranty:

• 2-Year System Warranty

• 1-Year Battery Warranty
