High-Resolution Imaging
Monitor vehicle activity using a Sony IMX477 camera and Full HD capture.
Winstar Road Supply is a leader in traffic-safety technology, delivering municipal-grade camera systems designed to improve roadway visibility, strengthen community security, and support safer public spaces. Our mission is to provide reliable, all-weather monitoring backed by professional US-based support.
The Winstar Municipal Traffic Camera Monitoring System provides high-definition video surveillance to monitor vehicle, pedestrian, and community activity in real time. Built for municipalities and law enforcement, this system is well-suited for roads, intersections, public facilities, and areas of elevated risk such as high-crime zones or drug activity hot spots. Its advanced optics and low-light performance ensure clear, consistent video capture day or night, in any weather. Municipalities can configure the system for roadway monitoring, pedestrian safety, neighborhood watch programs, or general security applications. This system is fully upgradeable — allowing municipalities to begin with camera-based monitoring today and later expand with radar and license plate recognition (LPR) for complete traffic data collection and enforcement.
With IP65-rated weather protection, AC or solar power options, and secure web-based control, the system delivers dependable performance and flexible deployment across diverse environments.
The system offers flexible mounting options and can be installed on nearly any suitable round pole, including a wide range of pole diameters and heights. Mounting brackets can be configured for larger-diameter poles, while the camera can be positioned to accommodate the specific roadway, viewing distance, and site conditions.
For long-term reliability and high-volume operation, we recommend A/C Wired power with a direct ethernet connection, installed by a Winstar Professional Installation Partner or a qualified local contractor. Please review our Recommended Installation Guide and Specifications.
Each Winstar Municipal Traffic Camera Monitoring System is custom made to order, please allow 1-3 weeks lead time.
Recommended Installation Guide
WinstarCloud Administrator User Manual
Winstar™ Municipal Traffic Camera Monitoring System
1 Year Free WinstarCloud Platform Subscription
1 Year Free 4G/5G Cellular Data Plan
Key Features
For detailed technical specifications, hardware ratings, and configuration options, please see the linked Technical Specifications document above.
Warranty:
2-Year System Warranty
1-Year Battery Warranty
FREE US SHIPPING* Available within the continental United States. Additional shipping charges may apply for specific delivery locations or for Alaska, Hawaii, U.S. territories, or international destinations.
*The product images shown may not be an exact representation of the product.
PRODUCT INFORMATION · MUNICIPAL
Explore the equipment, technical specifications, power options, connectivity, and configuration choices available for the Winstar Municipal Traffic Camera Monitoring System.
MUNICIPAL ROADWAY PROGRAMS
High-resolution camera monitoring supports roadway observation and traffic review. Speed radar and automatic license plate recognition are separate capabilities, not included in this camera-monitoring configuration.
Monitor vehicle activity using a Sony IMX477 camera and Full HD capture.
Low-light monitoring, motorized zoom, and built-in infrared night vision support day and night coverage.
WinstarCloud supports remote visibility, compatible event records, monitoring, and exports based on the selected equipment configuration.
Choose wired power or appropriately sized solar/battery configurations, with network options suited to the roadway or facility.
TECHNICAL SPECIFICATIONS
Only the capabilities applicable to this product type appear below. Final equipment and optional accessories depend on the order configuration.
POWER & CONNECTIVITY
System requirements vary by site, traffic volume, operating hours, camera/radar modules, and connectivity needs. Wired AC with Ethernet is recommended for long-term and higher-demand installations.
Optional solar configurations for locations without readily available electrical service.
Recommended for permanent installations and higher-volume data collection.
Choose connections appropriate for the deployment environment and data plan.
WINSTARCLOUD & DATA ACCESS
Access the records supported by this specific system—speed readings, camera imagery, plate events, or combined records as configured.
One year of platform subscription is listed as included with these systems.
Year 1 IncludedThe descriptions list a first-year 4G/5G data plan. Confirm the qualifying connectivity configuration when ordering.
Year 1 ListedCloud and cellular renewals depend on selected equipment, data usage, and plan. Review current terms before purchase.
Request DetailsPlatform access and cellular data renewals are based on the selected system, usage, and connectivity plan. Confirm service and renewal terms when configuring your order.
OPTIONS & SUPPORT
Confirm your goals, power availability, available communications, mounting conditions, and any agency requirements before finalizing an order.
A camera-first solution; discuss radar upgrades separately if needed.
Review pole suitability, roadway geometry, power capacity, enclosure configuration, and nearby network availability.
Define the data needed for reports, alerts, and ongoing monitoring.
Two-year system warranty and one-year battery warranty are listed for this product range.
ORDER INFORMATION
System configurations and site needs should be reviewed before installation.
APPLICATIONS
The Traffic Camera Monitoring System supports municipalities, transportation agencies, and public roadway programs. Capabilities depend on the equipment selected; plate recognition and speed measurement are not interchangeable.
Support roadway studies, traffic monitoring, and public-safety planning.
Review camera-based activity, site access, and other roadway events where appropriate.
Use high-resolution imagery to better understand site or roadway activity.
Plan power, connectivity, data access, and potential future equipment additions as needs evolve.
CONNECTED TECHNOLOGY
WinstarCloud provides remote monitoring and access to compatible records from your configured system. Access supported camera events and imagery.
Remote System MonitoringCheck connected equipment and supported data remotely.
Traffic & Event InsightsReview compatible records and export available information for analysis.
Configured ConnectivityChoose wired Ethernet, Wi-Fi, cellular, or an available satellite option appropriate for the deployment.
COMMON QUESTIONS
Important answers about capabilities, installation, WinstarCloud, warranties, and expected shipping.
Not in this base configuration. This listing describes a camera system without a dedicated speed-radar sensor. Ask about adding a radar-equipped system if speed measurement is required.
Yes. The listed camera uses a 12.3MP Sony IMX477 sensor with 1920×1080 Full HD capture and motorized lens features. Final options vary by configuration.
No. Automatic license plate recognition is not part of this base model. Select an LPR-equipped camera system if plate recognition is necessary.
Yes. Wired AC is an option, and solar configurations are listed with 100W or 200W panels. The battery configuration is 12V 100Ah LiFePO₄. Solar sizing varies with site and equipment configuration.
Listed connections include 100 BASE-TX Ethernet, Wi-Fi 802.11 b/g/n, and configured cellular service. Optional Starlink is described for suitable deployments. AC with direct Ethernet is recommended for higher-volume permanent installations.
The product descriptions list one year of WinstarCloud access and a first-year cellular data plan. Qualifying connectivity, activation, coverage, and renewal terms depend on the ordered configuration. Renewal costs and data requirements should be confirmed against the chosen service plan.
Yes. Camera-equipped systems include built-in infrared night vision, low-light operation, and motorized zoom for day and night monitoring. The listed IR illuminator uses 850 nm infrared lighting with a specified range of up to 65 ft (20 m) under suitable site conditions. Actual nighttime image quality and coverage depend on installation and lighting conditions.
Approximately 1–3 weeks; custom-built to order. Standard listings specify a two-year system warranty and one-year battery warranty. Shipping is listed as free within the continental United States, subject to stated exclusions.
PROJECT SUPPORT
Tell us the road type, lane count, goals, power availability, networking, and applicable agency requirements. Winstar can help review the appropriate system configuration.
We help municipalities, transportation agencies, and public roadway programs select connected monitoring systems, review installation needs, and plan for reliable long-term operation.
Get guidance selecting radar, imaging, LPR, or combined capabilities to support your goals.
Choose compatible power, communications, mounting, and equipment options.
Monitor supported traffic and event information from your configured WinstarCloud platform.
Get help with technical specifications, procurement, installation planning, and project questions.
Winstar can help customers plan equipment selection, financing, professional installation, and the operational requirements behind a connected system.
Tell us about your project, roadway, and preferred equipment configuration. Our team can help you evaluate the Winstar Municipal Traffic Camera Monitoring System and prepare a quotation.
